Canon Laser Shot LBP5000 User Manual

7-37
Problems on Installing the Network Board
7
Troubleshooting
Problems on Installing the Network Board
On checking the operation of the network board, if you find that all the indicators on
the network board are off, or the ERR indicator is on or keeps blinking for a long
time and does not go off, take the following measures.
NOTE
For details on problems on installing the CAPT software, see "Chapter 4
Troubleshooting" in Network Guide.
All the indicators on the network board are off.
Cause 1 The LAN cable is not connected properly or broken.
Remedy 1 Remove the LAN cable once, then connect it again.
Remedy 2 Replace the LAN cable with another one, then connect it.
Cause 2 The cable is connected to the UP-LINK (cascade) port on the hub.
Remedy 1 Connect the LAN cable to a port with a "X" mark.
Remedy 2 If the hub has a UP-LINK (cascade) switch, switch to "X".
Cause 3 A cross LAN cable is being used.
Remedy 1 Replace the cable with a straight LAN cable.
Remedy 2 Connect the cross LAN cable to the UP-LINK (cascade) port on the hub. If the
hub has a UP-LINK (cascade) switch, switch to "=".
NOTE
A cross LAN cable is a cable used to connect a printer and computer directly.
Cause 4 Cannot communicate with the hub.
Remedy 1 Make sure that the power of the hub is on.
Remedy 2 Set the DIP switches according to the transmission speed of the connected hub.
(See "Setting the Network Board," on p. 6-26)
Remedy 3 Replace the hub.
Cause 5 The network board is not installed properly.
Remedy Remove the network board once, then install it again.

Canon Laser Shot LBP5000 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (color, normal)	20 s
Print speed (black, normal quality, A4/US Letter)	8 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	125 sheets
Maximum input capacity	500 sheets
Envelopes sizes	B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	-
Power requirements	220 - 240V
Supported media weight(s)	60 - 163 g/m²
Compatible operating systems	Windows 98/Me/2000/XP/Server2003 Mac OS X version 10.2.8 -10.5.x Linux
Power consumption (standby)	18 W
Power consumption (printing)	207 W
Maximum duty cycle	35000 pages per month
Operating temperature (T-T)	10 - 30 °C
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	407 x 365 x 374 mm
