4-91
Printing a Document
4
Printer Status Window
[Consumables/Counters] Menu
Select [Consumables/Counters] from the [Options] menu to display the
[Consumables/Counters] dialog box. In the [Consumables/Counters] dialog box,
icons and meanings that indicate life of toner cartridges of each color and the
number of total printed pages are displayed.
You can obtain the same result by clicking [ ] (Consumables/Counters) in the
Printer Status Window.
[Utility] Menu
The [Utility] menu performs calibration of the printer or Configuration Page Print.
■ [Calibration]
Performs calibration of the printer manually. Perform calibration when the colors have
changed and the data is not printed in the correct colors (specified colors) or a color
deviation occurs. For more details, see "Calibrating the Printer," on p. 5-17.
■ [Cleaning]
When the front or back of the printed paper has smudge marks, the fixing roller needs to
be cleaned. Print quality deterioration can be prevented by cleaning the fixing roller. For
more details, see "Cleaning the Fixing Roller," on p. 5-22.
■ [Configuration Page Print]
Prints the optional settings of the printer, the settings for [Device Settings] in the [Options]
menu, and the current printer status such as the total number of printed pages. For more
details, see "Confirming the Printer Features," on p. 7-41.
■ [Network Status Print] (Only when the network board is installed)
Prints the version of the optional network board or the TCP/IP settings. For more details,
see "Chapter 4 Troubleshooting" in Network Guide.

Canon Laser Shot LBP5000 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (color, normal)	20 s
Print speed (black, normal quality, A4/US Letter)	8 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	125 sheets
Maximum input capacity	500 sheets
Envelopes sizes	B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	-
Power requirements	220 - 240V
Supported media weight(s)	60 - 163 g/m²
Compatible operating systems	Windows 98/Me/2000/XP/Server2003 Mac OS X version 10.2.8 -10.5.x Linux
Power consumption (standby)	18 W
Power consumption (printing)	207 W
Maximum duty cycle	35000 pages per month
Operating temperature (T-T)	10 - 30 °C
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	407 x 365 x 374 mm
