8-15
Windows Firewall
8
Appendix
Windows Firewall
Windows Firewall is a feature of Windows XP Service Pack 2 and other operating
systems that protects your computer by blocking unauthorized access over the
network.
Because of this, you need to configure Windows Firewall to unblock communication
if you are using the printer with an operating system that is equipped with Windows
Firewall.
The following settings are required on the print server (the computer to which the
printer is directly connected) and client computers (the computers that use the
printer via the network).
IMPORTANT
If you want to copy "CAPT Windows Firewall Utility" to your hard disk to run it, copy all of
the files (CNAC4FW.EXE, CAPTRGFW.DLL, and CNAC4FW.INI) from the [WF_UTIL]
folder on the supplied "LBP5000 User Software" CD-ROM to your hard disk.
Setting See
Print
server
■ When installing CAPT Software from CD-ROM Setup
The [Warning] dialog box appears during the installation.
Click [Yes] to configure Windows Firewall to unblock
communication with the client computers.
See p. 3-5
■ When installing CAPT Software from [Add Printer Wizard] or
[Windows Explorer]
Configure Windows Firewall to unblock communication with
the client computers using "CAPT Windows Firewall Utility".
See p. 8-16
Clients
Configure Windows Firewall to unblock communication with the
print server.
See p. 8-19

Canon Laser Shot LBP5000 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (color, normal)	20 s
Print speed (black, normal quality, A4/US Letter)	8 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	125 sheets
Maximum input capacity	500 sheets
Envelopes sizes	B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	-
Power requirements	220 - 240V
Supported media weight(s)	60 - 163 g/m²
Compatible operating systems	Windows 98/Me/2000/XP/Server2003 Mac OS X version 10.2.8 -10.5.x Linux
Power consumption (standby)	18 W
Power consumption (printing)	207 W
Maximum duty cycle	35000 pages per month
Operating temperature (T-T)	10 - 30 °C
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	407 x 365 x 374 mm
