Canon Laser Shot LBP5000 User Manual

7-32
Troubleshooting
7
Installation Problems
Uninstalling the USB Class Driver
Uninstalling the USB class driver is required when you cannot install the CAPT
software properly after uninstalling it once or when you cannot uninstall the CAPT
software.
1 Make sure that the computer is connected to the printer with
the USB cable and that the printer is ON.
2 From the [Start] menu, select [Control Panel], and then click
[Add or Remove Programs].
For Windows 98/Me/2000: From the [Start] menu, select [Settings] ➞ [Control
Panel], and then double-click [Add/Remove Programs].
For Windows Server 2003: From the [Start] menu, select [Control Panel] ➞ [Add
or Remove Programs].
3 Make sure that [Canon LBP5000] is not displayed in the [Add
or Remove Programs] dialog box, and then click [ ].
For Windows 2000: Make sure that [Canon LBP5000] is not displayed in the
[Add/Remove Programs] dialog box, and then click [ ].
For Windows 98/Me: Make sure that [Canon LBP5000] is not displayed in the
[Add/Remove Programs Properties] dialog box, and then click [ ].

Canon Laser Shot LBP5000 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (color, normal)	20 s
Print speed (black, normal quality, A4/US Letter)	8 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	125 sheets
Maximum input capacity	500 sheets
Envelopes sizes	B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	-
Power requirements	220 - 240V
Supported media weight(s)	60 - 163 g/m²
Compatible operating systems	Windows 98/Me/2000/XP/Server2003 Mac OS X version 10.2.8 -10.5.x Linux
Power consumption (standby)	18 W
Power consumption (printing)	207 W
Maximum duty cycle	35000 pages per month
Operating temperature (T-T)	10 - 30 °C
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	407 x 365 x 374 mm
