Canon Laser Shot LBP5000 User Manual

8-19
Appendix
8
Windows Firewall
Configuring Windows Firewall to Unblock Communication
with the Print Server
IMPORTANT
If you do not perform the following settings on the client computers, the printer status may
not be displayed properly in the Printer Status Window, and some of the printer functions
may not operate properly.
1 From the [Start] menu, select [Control Panel].
2 Click [Network and Internet Connections], then click
[Windows Firewall].
3 In the [Exceptions] sheet in the [Windows Firewall] dialog box,
select the [File and Printer Sharing] check box, and then click
[OK].
Windows Firewall is configured to unblock communication with the print server.

Canon Laser Shot LBP5000 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Time to first page (color, normal)	20 s
Print speed (black, normal quality, A4/US Letter)	8 ppm
Internal memory	8 MB
Maximum internal memory	- MB
Sound pressure level (printing)	50 dB
Total input capacity	250 sheets
Total output capacity	125 sheets
Maximum input capacity	500 sheets
Envelopes sizes	B5, C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	-
Power requirements	220 - 240V
Supported media weight(s)	60 - 163 g/m²
Compatible operating systems	Windows 98/Me/2000/XP/Server2003 Mac OS X version 10.2.8 -10.5.x Linux
Power consumption (standby)	18 W
Power consumption (printing)	207 W
Maximum duty cycle	35000 pages per month
Operating temperature (T-T)	10 - 30 °C
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	407 x 365 x 374 mm
