2. Product Overview
This chapter provides a high-level overview of the system features and available options as
supported in different system models within this product. Greater detail for each major
sub-system, feature, or option is provided in the following chapters.
Table 2. Chenbro RM23712 Feature Set
Feature
Description
Chassis Type
2U Rack Mount Chassis
Server Board
• Intel®Server Board S2600WT w/Dual 1GbE ports – (Intel product code - S2600WT2)
Processor Support
• Two LGA2011-3 (Socket R3) processor sockets
• Support for one or two Intel®Xeon®processors E5-2600 v3 product family
• Maximum supported Thermal Design Power (TDP) of up to 145 W.
24 DIMM slots – 3 DIMMs/Channel – 4 memory channels per processor
Memory
• Registered DDR4 (RDIMM), Load Reduced DDR4 (LRDIMM)
• Memory data transfer rates:
o DDR4 RDIMM: 1600 MT/s (3DPC), 1866 MT/s (2DPC) and 2133 MT/s (1DPC)
o DDR4 LRDIMM: 1600 MT/s (3DPC), 2133 MT/s (2DPC& 1DPC)
• DDR4 standard I/O voltage of 1.2V
Chipset
Intel®C612 chipset
External I/O
connections
• DB-15 Video connectors
o Back on storage systems
• RJ-45 Serial Port A connector
• Dual RJ-45 Network Interface connectors supporting either :
o 1 GbERJ-45 connectors
• Dedicated RJ-45 server management port
• Three USB 2.0 / 3.0 connectors on back panel
• Two USB 2.0 / 3.0 ports on front panel (non-storage models only)
• One USB 2.0 port on rack handle (storage models only)
Internal I/O
connectors/
Headers
• One Type-A USB 2.0 connector
• One 2x5 pin connector providing front panel support for two USB 2.0 ports
• One 2x10 pin connector providing front panel support for two USB 2.0 / 3.0 ports
• One 2x15 pin SSI-EEB compliant front panel header
• One 2x7pin Front Panel Video connector
• One 1x7pin header for optional Intel®Local Control Panel (LCP) support
• One DH-10 Serial Port B connector
Intel®I/O Module
Accessory
Options
The server board includes a proprietary on-board connector allowing for the installation of
a variety of available I/O modules. An installed I/O module can be supported in addition to
standard on-board features and add-in PCIe cards.
• AXX4P1GBPWLIOM – Quad port RJ45 1 GbEbased on Intel®Ethernet Controller I350
• AXX10GBTWLIOM3 – Dual port RJ-45 10GBase-T based on Intel® Ethernet Controller x540
• AXX10GBNIAIOM – Dual port SFP+ 10 GbEmodule based on Intel®82599 10 GbEcontroller
• AXX1FDRIBIOM – Single port QSFP FDR56 GT/S speed InfiniBand* module
• AXX2FDRIBIOM – Dual port QSFP FDR56 GT/S speed infiniband* module
• AXX1P40FRTIOM – Single port QSFP+ 40 GbEmodule
• AXX2P40FRTIOM – Dual port QSFP+ 40 GbEmodule
System Fans
• Six managed hot swap system fans
• One power supply fan for each installed power supply module
