RM23712 TPS
4
Concurrent support for up to three riser cards.
• Riser #1 – PCIe* Gen3 x24 – up to 3 PCIe slots
• Riser #2 – PCIe* Gen3 x24 – up to 3 PCIe slots
• Riser #3 – PCIe* Gen3 x8 + DMI x4 (operating in PCIe mode) – up to 2 PCIe slots (Optional)
With three riser cards installed, up to 8 possible add-in cards can be supported:
•4 Full Height / Full Length + 2 Full Height / Half Length add-in cards via Risers #1 and #2
•2 low profile add-in cards via Riser #3 (option)
See Chapter 7 for available riser card options
• Integrated 2D Video Controller
•16 MB DDR3 Memory
• Intel® Trusted Platform Module (TPM) - AXXTPME5 (Accessory Option)
• Integrated Baseboard Management Controller, IPMI 2.0 compliant
• Support for Intel®Server Management Software
• On-board RJ45 management port
• Advanced Server Management via an Intel®Remote Management Module 4
Lite (Accessory Option)
Hot Swap Backplane Options:
Note: All available backplane options have support for SAS 3.0 (12 Gb/sec)
•12 x 3.5” SAS/SATA
SAS /SATA Backplane Options
• Internal mount for 2.5” drive configurations
Storage Bay Options:
•12 x 3.5” SAS/SATA Hot Swap Drive Bay
Supported Rack
Mount Kit
Accessory
Option
• 84H314610-003 – Tool-less rack mount rail kit – 560mm max travel length
2.1 Operating System Support
As of this writing, the Chenbro RM23712 provides support for the following operating systems.
This list will be updated as new operating systems are validated by Chenbro.
Table 3. Operating System Support List
Operating System
Validation Level(P)
Windows Server 2012* R2 with Hyper-Vx64
& EFI
Red Hat Enterprise Linux* 7.0
with KVM x64 & UEFI
SuSELinux Enterprise Server* 12 with XEN x64
Red Hat Enterprise Linux 6U5 with KVM x64 &
UEFI
SuSELinux Enterprise Server 11 SP4 with
XEN x64
Windows Server 2008 R2 SP1
Table 4. Operating System Validation Levels
Operating System Validation Levels
