Cisco TelePresence SX20 User Manual

18
D1534504 User Guide
Cisco TelePresence
Produced: November 2016 for CE 8.2
All contents © 2010–2016
Cisco Systems, Inc. All rights reserved.
This feature allows you to be in a call
with two parties, but one at a time
only.
You may swap whom you are in call
with, and you may connect the two
together, while you leave the call.
About Consult and Transfer
Locate
whom to
call in the
usual way.
Assume that
you are in a
call. Tap Hold.
Tap + Place New Call or tap
Resume to go back to the one
you were in call with (to undo
your action).
Place the call in the
usual way.
You are now in the new
call while the one you
were in call with still is
on hold.
Tap Swap to
go between
the two parties
and Transfer
to connect the
two together, while you leave the call.
Consult and Transfer
Transfer Call

Cisco TelePresence SX20 Specifications

General

Digital zoom	5 x
Optical zoom	2.5 x
Aspect ratio	16:9
Supported video modes	1080p, 576p, 720p
Supported graphics resolutions	176 x 144, 352 x 288, 704 x 576, 720 x 480, 720 x 576, 1280 x 768, 1280 x 800, 1280 x 960, 1024 x 576 (WSVGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1360 x 768 (WXGA), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
Line-in	Yes
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	40 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Voice codecs	G.711, G.722, G.722.1

Weight and Dimensions

Depth	180 mm
Width	300 mm
Height	34 mm
Weight	1400 g
