Cisco TelePresence SX20 User Manual

76
D1534504 User Guide
Cisco TelePresence
Produced: November 2016 for CE 8.2
All contents © 2010–2016
Cisco Systems, Inc. All rights reserved.
If you enable Auto Answer the
system will respond by itself to
incoming calls after a delay specied
by you. Note that an activated auto
answer may not provide you with
the privacy desired. In the example
shown here Auto Answer is set to
O.
On certain occasions you may have
to change the bandwidth (and
hence the quality) of the call. Some
congurations may have dierent
incoming and outgoing bandwidths
(typically ADSL connections), and
you may specify the default call rate
to ensure a stable video quality.
The default protocol may also be
specied. In the example shown, the
protocol has been set to SIP.
Caution! There is no Cancel
function letting you exit the menu
undoing any changes you have
made. Take care!
Settings
Administrator Settings—Call Details
About Call Details
To exit
Administrator
Settings, tap
Back.
To exit Settings
as such, tap
Exit.
Note that there
is no Cancel
function letting
you exit the
menu undoing
any changes you
have made.
Take care!

Cisco TelePresence SX20 Specifications

General

Digital zoom	5 x
Optical zoom	2.5 x
Aspect ratio	16:9
Supported video modes	1080p, 576p, 720p
Supported graphics resolutions	176 x 144, 352 x 288, 704 x 576, 720 x 480, 720 x 576, 1280 x 768, 1280 x 800, 1280 x 960, 1024 x 576 (WSVGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1360 x 768 (WXGA), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
Line-in	Yes
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	40 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Voice codecs	G.711, G.722, G.722.1

Weight and Dimensions

Depth	180 mm
Width	300 mm
Height	34 mm
Weight	1400 g
