Cisco TelePresence SX20 User Manual

49
D1534504 User Guide
Cisco TelePresence
Produced: November 2016 for CE 8.2
All contents © 2010–2016
Cisco Systems, Inc. All rights reserved.
Contacts
Add Someone to Favorites, While in a Call
There are several ways to add
someone to the list of Favorites and
one of them allows you to do this
while in a call.
You may, after a call, realize that
you should have added the one
you were in call with to the list of
Favorites. To do this use Recents
and Add To Favorites from there, see
“Call Recents” on page 47.
About this feature
Edit the
entry, if needed.
In a call, tap the avatar.
In a video conference with
several participants, tap
the avatar that you want to
add to Favorites.
Tap Add To Favorites.
Tap Close, to hide the
keyboard.
Tap Save to add
new Favorite.

Cisco TelePresence SX20 Specifications

General

Digital zoom	5 x
Optical zoom	2.5 x
Aspect ratio	16:9
Supported video modes	1080p, 576p, 720p
Supported graphics resolutions	176 x 144, 352 x 288, 704 x 576, 720 x 480, 720 x 576, 1280 x 768, 1280 x 800, 1280 x 960, 1024 x 576 (WSVGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 768 (WXGA), 1360 x 768 (WXGA), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
Line-in	Yes
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Ethernet LAN data rates	10, 100, 1000 Mbit/s
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	40 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Voice codecs	G.711, G.722, G.722.1

Weight and Dimensions

Depth	180 mm
Width	300 mm
Height	34 mm
Weight	1400 g
