10-20
Catalyst 3750 Switch Software Configuration Guide
78-16180-02
Chapter 10 Configuring 802.1x Port-Based Authentication
Configuring 802.1x Authentication
To disable multiple hosts on the port, use the no dot1x host-mode multi-host interface configuration
command.
This example shows how to enable 802.1x and to allow multiple hosts:
Switch(config)# interface gigabitethernet2/0/1
Switch(config-if)# dot1x port-control auto
Switch(config-if)# dot1x host-mode multi-host
Configuring a Guest VLAN
When you configure a guest VLAN, clients that are not 802.1x-capable are put into the guest VLAN
when the server does not receive a response to its EAPOL request/identity frame. Clients that are
802.1x-capable but fail authentication are not granted access to the network. The switch supports guest
VLANs in single-host or multiple-hosts mode.
Beginning in privileged EXEC mode, follow these steps to configure a guest VLAN. This procedure is
optional.
To disable and remove the guest VLAN, use the no dot1x guest-vlan interface configuration command.
The port returns to the unauthorized state.
This example shows how to enable VLAN 2 as an 802.1x guest VLAN:
Switch(config)# interface gigabitethernet2/0/2
Switch(config-if)# dot1x guest-vlan 2
Step 3
dot1x host-mode multi-host Allow multiple hosts (clients) on an 802.1x-authorized port.
Make sure that the dot1x port-control interface configuration command
set is set to auto for the specified interface.
Step 4
end Return to privileged EXEC mode.
Step 5
show dot1x interface interface-id Verify your entries.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
interface interface-id Specify the port to be configured, and enter interface configuration mode.
For the supported port types, see the “802.1x Configuration Guidelines”
section on page 10-12.
Step 3
dot1x guest-vlan vlan-id Specify an active VLAN as an 802.1x guest VLAN. The range is 1 to
4094.
You can configure any active VLAN except an internal VLAN (routed
port), an RSPAN VLAN, or a voice VLAN as an 802.1x guest VLAN.
Step 4
end Return to privileged EXEC mode.
Step 5
show dot1x interface interface-id Verify your entries.
Step 6
copy running-config startup-config (Optional) Save your entries in the configuration file.
