A
B
D
C
128
III
The ISOFIX anchoring system
The three second-row rear seats as well as the front
passenger seat position on your vehicle are equipped
with the regulation ISOFIX anchoring points.
There are 3 rings for each seat position:
- Two « bottom » rings
A and B, between the seat cush-
ion and the backrest. They are approx. 28 cm apart.
- A « top » ring
C, behind a cover at the top of the back-
rest for the second-row seats, and at the bottom right
of the seat base for the front passenger seat position.
ISOFIX child seats have two latches which are easy to
attach on the two « bottom » rings A and B.
Top ring C
1. To attach the top ring, unclip the cover D.
2. Raise the head restraint of the vehicle seat, then
pass the attachment between the uprights.
3. Next secure the attachment on the « top » ring C
(second row seats).
4. Tension the top belt.
This fixing system is designed for children weighing
up to 18 kg.
CHILD RESTRAINTS
