1
2
3
4
VI
177
FRONT LENS
Dipped beam
Main beam
Sidelamp
Direction indicator
Note : A slight misting may appear on the surface of
the headlamp glass in certain conditions of use.
CHANGING BULBS -
HALOGEN HEADLAMPS
Dipped beam
1. Remove the rubber plug
.
2. Rotate the bulb-holder a quarter turn anti-clockwis
e
and remove it from its housing.
3. Replace the bulb H7.
4. Reposition the bulb-holder by pushing it in, tighte
-
ning it by a quarter turn (clockwise).
5. Put back the rubber plug.
Changing a halogen bulb should only be done after the
headlamp has been
switched off for a few minutes (risk of serious burn).
Do not touch the bulb directly with your fingers, use lint-fre
e cloths.
It is imperative to use only anti-U.V. type bulbs in
order not to damage the headlamp.
