ComAp InteliLite MRS16 User Manual

InteliLite Global Guide
46
Connection using WinScope
Image 5.3 WinScope screen - select direct connection
5.2.2 RS232
It is possible to connect to the controller using RS232 direct connection (serial port or USB to RS232 converter
may be used). The following settings need to be checked in the controller:
COM1 Mode (page 300) = Direct
Controller Address (page 161) has to be set to the same value as in the PC tool
Connection using LiteEdit2015
Image 5.4 First screen of LiteEdit2015 - select connect to controller
