InteliLite Global Guide
559
Outputs
No outputs.
Description
This block issues alarms of configured type and text when appropriate binary input is activated.
Image 9.12 Configuration of Force Prot block
Available protections are:
Monitoring
HistRecOnl
AL Indic
Wrn
Wrn+BOC
BOC
Wrn+Sd
Sd
Note: Maximal number of characters for alarmlist message is 15.
Note: Prefix of protection (e.g. Wrn, Sd, BOC) is added automatically into alarmlist message.
6 back to List of PLC blocks
8.2 Alarms
8.2.1 Alarms level 1 559
8.2.2 Alarms level 2 581
8.2.3 Fail sensor and other types 599
What alarms are:
The controller evaluates two levels of alarms. For more information see Alarm management on page 82.
8.2.1 Alarms level 1
Warnings 562
Other type 576
