InteliLite Global Guide
616
you want to program into the module (in LiteEdit2015).
Press the OK button to start upgrade of firmware.
The firmware update process may be performed via any kind of connection including connection via the same
module in which the firmware is to be updated. The connection is reestablished again automatically when the
update process is finished.
8.3.2 CAN modules
Communication modules 616
Extension modules 621
The available communication CAN modules are:
I-LB+ - communication local bridge
The available extension CAN modules are:
Inteli AIN8 - extension CAN module with 8 analog inputs
Inteli IO8/8 - extension CAN module with 8 binary inputs, 8 binary outputs and 2 analog outputs
this CAN module can be switched to Inteli IO 16/0 - extension CAN module with 16 binary inputs and 2
analog outputs
Maximal number of CAN modules is 2. Modules are configured via LiteEdit2015. There are 2 slots for CAN
modules.
Note: I-LB+ communication module is not configured via LiteEdit2015 into controller CAN module slot. Also
this module is not counted into maximal number of CAN modules.
Note: It is possible to configure all combinations of CAN modules (same modules in both slots or different
modules in both slots).
Communication modules
I-LB+ 616
I-LB+
I-LB+ is communication modules for communication with all devices connected to CAN2 bus. Speed for
direct/modem connection can be up to 57600 bps. I-LB+ can be connected with PC via USB, RS232 or RS485.
