Section 4 - Managing the Access Point
Figure 19 - Scheduler Conguration
Field Description
Global Scheduler
Mode
A global switch to enable or disable the scheduler feature. The default is Disable.
Scheduler Operational Status
Status The operational status of the Scheduler. The range is Up or Down. The default is Down.
Reason Provides additional information about the status. The reason can be one or more of the
following:
•) IsActive – Operational status is up.
•) CongDown – Operational status is down because global conguration is disabled.
•) TimeNotSet – Operational status is down because the AP time has not been set,
either manually or by specifying an NTP server to use.
•) ManagedMode– Operational status is down because the AP is in managed mode.
Scheduler Prole The Scheduler prole denes the list of proles names that can be associated to the VAP or
Radio conguration. Rules are associated with a named scheduler prole. You can dene up
to 16 scheduler prole names. By default, no proles are created.
The prole name can be up to 32 alphanumeric characters. Click Add to add the prole
name.
Rule Conguration Each scheduler prole may have up to 16 periodic rules. The list of parameters for each
periodic rule are described below.
Select Prole Select the prole name from the menu.
Set Schedule The day of the week. Range is: Daily, Weekday (Monday to Friday), Weekend (Saturday
and Sunday), Monday, Tuesday, Wednesday, Thursday, Friday, Saturday, Sunday. The
default is Daily.
Start Time The time when the radio or VAP will be operationally enabled. The time is in HH:MM 24-hour
format. The range is <00-24>:<00-59>. The default is 00:00.
End Time The time when the radio or VAP will be operationally disabled. The time is in HH:MM 24-
hour format. The range is <00-24>:<00-59>. The default is 00:00.
Table 20 - Scheduler Conguration
To change an existing rule, select the rule, update the values in the Rule Conguration area, and click Modify Rule.

D-Link DWL-2600AP Specifications

General

Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	Yes
LED indicators	Power, Stand-by, Status, WAN, WLAN
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	WEP, WPA, WPA2
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	160 mm
Height	45 mm
Weight	240 g
Dimensions (WxDxH)	160 x 160 x 45 mm
