User's Manual
7
Icon
Name
Function
HDD
HDD status indicator light
The blue light is on when the
HDD malfunctions.
NET
Network status indicator light
The blue light is on when the
network connection is
abnormal.
POWER
Power status indicator light
The blue light is on when the
power connection is normal.
USB 2.0 port
Connect to peripheral USB 2.0
storage device, mouse, burner
and more.
2.1.3 N82B2P/N82B3P/N82B5P
The figure is for reference only.
The NVR22-I/NVR22-I2 front panel is shown as below.
Figure 2-12 Front panel
The NVR22-P-I/NVR22-P-I2 front panel is shown as below.
Figure 2-13 Front panel
The NVR22-8P-I/NVR22-8P-I2 front panel is shown as below.
Figure 2-14 Front panel
The NVR22-16P-I/NVR22-16P-I2 front panel is shown as below.
Figure 2-15 Front panel
The NVR52-EI/NVR52-8P-EI/NVR52-16P-EI front panel is shown as below.
