Dahua N42C3P User Manual

User's Manual
13
Name
Function
MIC OUT
Audio output port
Audio output port. It is to output the analog
audio signal to the devices such as the sound
box.
●
Bidirectional talk output.
●
Audio output on 1-window video monitor.
●
Audio output on 1-window video
playback.
1–4
Alarm input port
1–4
●
There are two types; NO (normal open)/NC
(normal close).
●
When your alarm input device is using
external power, please make sure the
device and the NVR have the same ground.
GND
Alarm input ground port.
N1, N2
Alarm output port
1–2
●
2 groups of alarm output ports. (Group 1:
port NO1–C1,Group 2: port NO2–
C2).Output alarm signal to the alarm
device. Please make sure there is power to
the external alarm device.
●
NO: Normal open alarm output port.
●
C:Alarm output public end.
C1, C2
A
RS-485
communication
port
RS485_A port. It is the cable A. You can
connect to the control devices such as speed
dome PTZ.
B
RS485_B. It is the cable B. You can connect to
the control devices such as speed dome PTZ.
Network port
10/100/1000 Mbps self-adaptive Ethernet port.
Connect to the network cable.
USB port
USB port. Connect to mouse, USB storage
device, USB burner and more.
RS-232
RS-232 debug
COM
It is for general COM debug to configure IP
address or transfer transparent COM data.
HDMI
High Definition
Media Interface
High definition audio and video signal output
port. It transmits uncompressed high definition
video and multiple-channel data to the HDMI
port of the display device. HDMI version is 1.4.
VGA
VGA video output
port
VGA video output port. Output analog video
signal. It can connect to the monitor to view
analog video.
PoE PORTS
/
Built-in Switch. Support PoE.
For PoE series product, you can use this port to
provide power to the network camera.
