Specifications SiBE18-821_C
12 Specifications
1.2 BP Unit
50 Hz, 230 V
Note:
1. BP or Indoor Unit Max. Height - BP or Indoor Unit Min. Height
→
Max. 15 m.
Set up BP and indoor unit within 15 m height difference.
2. The piping connection must be cut so as to suit the piping sizes of the indoor unit which will be connected.
The same sizes should be used for the piping on the outdoor unit.
3. ( )* : including auxiliary piping length
Model BPMKS967B2B BPMKS967B3B
Connectable Indoor Units 1 ~ 2 Units 1 ~ 3 Units
Casing Color Paintingless
Power Consumption W 10 10
Running Current A 0.05 0.05
Refrigerant Type R-410A
Dimension (H × W × D) mm 180 × 294 (650)* × 350
Package Dimension (H × W × D) mm 257 × 738 × 427
Machine Weight (Mass) kg 7.5 8
Gross Weight (Gross Mass) kg 11 12
Number of Wiring Connections 4 for Interunit Wiring
Piping
Connection
(Brazing)
Liquid mm Main:
φ
9.5 × 1 / Branch:
φ
6.4 × 2 Main:
φ
9.5 × 1 / Branch:
φ
6.4 × 3
Gas mm Main:
φ
19.1 × 1 / Branch:
φ
15.9 × 2 Main:
φ
19.1 × 1 / Branch:
φ
15.9 × 3
Drain mm Drain Processingless
Heat Insulation Both Liquid and Gas Pipes
Max. Piping Length m —
Amount of Additional Charge g/m —
Max. Height Difference m —
Max. Combination kW 14.2 20.8
Min. Combination kW 2.0 2.0
Accessories
Installation Manual pc. 1
Reducer pc.
For Main
Liquid 1 (For I.D.
φ
6.4)
Gas 1 (For I.D.
φ
12.7)
Gas 1 (For I.D.
φ
15.9, 19.1)
For Branch
Liquid 1 (For I.D.
φ
9.5)
Gas 2 (For I.D.
φ
12.7, 9.5) 3 (For I.D.
φ
12.7, 9.5)
Hanger Metal pc. 4
Screws pc. 8 (M4 × 8)
Heat Insulation (2pc. is 1 set) 3 Sets 4 Sets
Binding Band pc. 2
Drawing No. C: 4D050058B
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
