Troubleshooting for Outdoor Unit SiBE18-821_C

386 Troubleshooting

7.3 Actuation of Low Pressure Sensor

Remote

Controller

Display

Method of

Malfunction

Detection

Detection by the pressure value with the low pressure sensor

Malfunction

Decision

Conditions

When the low pressure is dropped under specific pressure

Operating pressure: 0.07 MPa

Supposed

Causes



Abnormal drop of low pressure (Lower than 0.07 MPa)



Defective low pressure sensor



Defective outdoor unit PCB



Stop valve is not opened.
