SiBE18-821_C Remote Controller
Printed Circuit Board Connector Wiring Diagram 63
4.2 Wireless Remote Controller
4.2.1 BRC7E530W, BRC7F532F, BRC7EA63W
Connectors and
Other Parts
[A3P]: Signal Receiver PCB
[A4P]: Display PCB
1) X1A Connector for display PCB
2) X2A Connector for control PCB
3) SS1 MAIN / SUB setting switch
4) SS2 Address setting switch
∗
Refer to page 163 for detail.
1) X1A Connector for signal receiver PCB
2) BS1 Forced operation ON/OFF button
3) LED1 (H1P) LED for operation (red)
4) LED2 (H2P) LED for timer (green)
5) LED3 (H3P) LED for filter cleaning sign (red)
6) LED4 (H4P) LED for defrost operation (orange)
To Next Page
