Specifications 21
Duct Connected Type
50 Hz, 230 V
Model
FDXS25EAVMB FDXS35EAVMB
Cooling Heating Cooling Heating
Rated Capacity 2.5 kW Class 3.5 kW Class
Front Panel Color
——
Airflow Rates
m³/min
(cfm)
H 8.7 (307) 8.7 (307) 8.7 (307) 8.7 (307)
M 8.0 (282) 8.0 (282) 8.0 (282) 8.0 (282)
L 7.3 (258) 7.3 (258) 7.3 (258) 7.3 (258)
SL 6.2 (219) 6.2 (219) 6.2 (219) 6.2 (219)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 62 62
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.48 0.48 0.48 0.48
Power Consumption (Rated) W 71 71 71 71
Power Factor (Rated) % 64.3 64.3 64.3 64.3
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 200 × 700 × 620 200 × 700 × 620
Packaged Dimensions (H × W × D) mm 274 × 906 × 751 274 × 906 × 751
Weight (Mass) kg 21 21
Gross Weight (Gross Mass) kg 29 29
Operation
Sound
H / M / L / SL dBA 35 / 33 / 31 / 29 35 / 33 / 31 / 29 35 / 33 / 31 / 29 35 / 33 / 31 / 29
Sound Power dBA 53 53 53 53
External Static Pressure Pa 30 30
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm VP20 (O.D.
φ
26 / I.D.
φ
20) VP20 (O.D.
φ
26 / I.D.
φ
20)
Drawing No. 3D060029 3D060030
Model
FDXS50CVMB FDXS60CVMB
Cooling Heating Cooling Heating
Rated Capacity 5.0 kW Class 6.0 kW Class
Front Panel Color
——
Airflow Rates
m³/min
(cfm)
H 12.0 (424) 12.0 (424) 16.0 (565) 16.0 (565)
M 11.0 (388) 11.0 (388) 14.8 (523) 14.8 (523)
L 10.0 (353) 10.0 (353) 13.5 (477) 13.5 (477)
SL 8.4 (297) 8.4 (297) 11.2 (395) 11.2 (395)
Fan
Type Sirocco Fan Sirocco Fan
Motor Output W 130 130
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.64 0.64 0.74 0.74
Power Consumption (Rated) W 140 140 160 160
Power Factor (Rated) % 95.1 95.1 94.0 94.0
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H × W × D) mm 200 × 900 × 620 200 × 1,100 × 620
Packaged Dimensions (H × W × D) mm 266 × 1,106 × 751 266 × 1,306 × 751
Weight (Mass) kg 27 30
Gross Weight (Gross Mass) kg 34 37
Operation
Sound
H / M / L / SL dBA 37 / 35 / 33 / 31 37 / 35 / 33 / 31 38 / 36 / 34 / 32 38 / 36 / 34 / 32
Sound Power dBA 55 55 56 56
External Static Pressure Pa 40 40
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping
Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm VP20 (O.D.
φ
26 / I.D.
φ
20) VP20 (O.D.
φ
26 / I.D.
φ
20)
Drawing No. 3D060033 3D065477
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
