SiBE18-821_C Thermistor Resistance / Temperature Characteristics
Troubleshooting 427
8. Thermistor Resistance / Temperature
Characteristics
Table 1 Table 2
Indoor unit : suction air R1T
: liquid pipe R2T
: indoor heat exchanger R3T
Outdoor unit : outdoor temperature R1T
: suction pipe 1 R3T
: outdoor heat exchanger R4T
: suction pipe 2 R5T
: subcooling heat exchanger gas pipe R6T
: liquid pipe 1 R7T
: liquid pipe 2 R8T
Outdoor unit : fin thermistor FINTH
TºC k
Ω
–10
–8
–6
–4
–2
-
-
88.0
79.1
71.1
0
2
4
6
8
64.1
57.8
52.3
47.3
42.9
10
12
14
16
18
38.9
35.3
32.1
29.2
26.6
20
22
24
26
28
24.3
22.2
20.3
18.5
17.0
30
32
34
36
38
15.6
14.2
13.1
12.0
11.1
40
42
44
46
48
10.3
9.5
8.8
8.2
7.6
50
52
54
56
58
7.0
6.7
6.0
5.5
5.2
60
62
64
66
68
4.79
4.46
4.15
3.87
3.61
70
72
74
76
78
3.37
3.15
2.94
2.75
2.51
80
82
84
86
88
2.41
2.26
2.12
1.99
1.87
90
92
94
96
98
1.76
1.65
1.55
1.46
1.38
T°C k
Ω
T°C k
Ω
T°C k
Ω
T°C k
Ω
–20 197.81 –19.5 192.08 30 16.10 30.5 15.76
–19 186.53 –18.5 181.16 31 15.43 31.5 15.10
–18 175.97 –17.5 170.94 32 14.79 32.5 14.48
–17 166.07 –16.5 161.36 33 14.18 33.5 13.88
–16 156.80 –15.5 152.38 34 13.59 34.5 13.31
–15 148.10 –14.5 143.96 35 13.04 35.5 12.77
–14 139.94 –13.5 136.05 36 12.51 36.5 12.25
–13 132.28 –12.5 128.63 37 12.01 37.5 11.76
–12 125.09 –11.5 121.66 38 11.52 38.5 11.29
–11 118.34 –10.5 115.12 39 11.06 39.5 10.84
–10 111.99 –9.5 108.96 40 10.63 40.5 10.41
–9 106.03 –8.5 103.18 41 10.21 41.5 10.00
–8 100.41 –7.5 97.73 42 9.81 42.5 9.61
–7 95.14 –6.5 92.61 43 9.42 43.5 9.24
–6 90.17 –5.5 87.79 44 9.06 44.5 8.88
–5 85.49 –4.5 83.25 45 8.71 45.5 8.54
–4 81.08 –3.5 78.97 46 8.37 46.5 8.21
–3 76.93 –2.5 74.94 47 8.05 47.5 7.90
–2 73.01 –1.5 71.14 48 7.75 48.5 7.60
–1 69.32 –0.5 67.56 49 7.46 49.5 7.31
0 65.84 0.5 64.17 50 7.18 50.5 7.04
1 62.54 1.5 60.96 51 6.91 51.5 6.78
2 59.43 2.5 57.94 52 6.65 52.5 6.53
3 56.49 3.5 55.08 53 6.41 53.5 6.53
4 53.71 4.5 52.38 54 6.65 54.5 6.53
5 51.09 5.5 49.83 55 6.41 55.5 6.53
6 48.61 6.5 47.42 56 6.18 56.5 6.06
7 46.26 7.5 45.14 57 5.95 57.5 5.84
8 44.05 8.5 42.98 58 5.74 58.5 5.43
9 41.95 9.5 40.94 59 5.14 59.5 5.05
10 39.96 10.5 39.01 60 4.96 60.5 4.87
11 38.08 11.5 37.18 61 4.79 61.5 4.70
12 36.30 12.5 35.45 62 4.62 62.5 4.54
13 34.62 13.5 33.81 63 4.46 63.5 4.38
14 33.02 14.5 32.25 64 4.30 64.5 4.23
15 31.50 15.5 30.77 65 4.16 65.5 4.08
16 30.06 16.5 29.37 66 4.01 66.5 3.94
17 28.70 17.5 28.05 67 3.88 67.5 3.81
18 27.41 18.5 26.78 68 3.75 68.5 3.68
19 26.18 19.5 25.59 69 3.62 69.5 3.56
20 25.01 20.5 24.45 70 3.50 70.5 3.44
21 23.91 21.5 23.37 71 3.38 71.5 3.32
22 22.85 22.5 22.35 72 3.27 72.5 3.21
23 21.85 23.5 21.37 73 3.16 73.5 3.11
24 20.90 24.5 20.45 74 3.06 74.5 3.01
25 20.00 25.5 19.56 75 2.96 75.5 2.91
26 19.14 26.5 18.73 76 2.86 76.5 2.82
27 18.32 27.5 17.93 77 2.77 77.5 2.72
28 17.54 28.5 17.17 78 2.68 78.5 2.64
29 16.80 29.5 16.45 79 2.60 79.5 2.55
30 16.10 30.5 15.76 80 2.51 80.5 2.47
