Troubleshooting for SA Indoor Unit SiBE18-821_C

364 Troubleshooting

5.2 Drain Water Level System Abnormality

Remote

Controller

Display

Method of

Malfunction

Detection

The float switch detects error.

Malfunction

Decision

Conditions

When the water level reaches its upper limit and when the float switch turns OFF

Supposed

Causes



Defective drain pump



Improper drain piping work



Clogged drain piping



Defective float switch



Defective indoor unit PCB



Defective short circuit connector X15A on indoor unit PCB
