DataCard CR805 Installation And Administrator's Guide

90 Printer Manager
Using custom magnetic stripe data formats is a two-step process. First, define the custom tracks
using MagStripeCustomTrack1, MagStripeCustomTrack2, and MagStripeCustomTrack3. Second,
apply the custom track using the settings on the MagStripeGeneral menu.
1. To use the defined custom track:
a. Open the MagStripeGeneral menu.
b. Select Custom for DataFormat1, DataFormat2, or DataFormat3 to use the custom track.
 MagStripeCustomTrack1 corresponds to DataFormat1
 MagStripeCustomTrack2 corresponds to DataFormat2
 MagStripeCustomTrack3 corresponds to DataFormat3
2. Click Set Current to apply the changes.
Laminator
The Laminator settings let you specify values when using a laminating system.
The Laminator setting displays in the Printer Setting menu only when a laminator is
attached to the printer.
Description Default Value
Current Value
(unit) Allowed Range
1) DebowDelay 1000 1000 [0 – 1500]
2) ExceptionCardDebow
Direction
Down Down
3) ExceptionCardDebow
DistanceDown
15 15 [0 – 150]
4) ExceptionCardDebow
DistanceUp
105 105 [0 – 150]
5) ExceptionCardDebow
DwellMs
1000 1000 [0 – 5000]
6) ExceptionCardImpress
Depth
0 0 [-250 – 250]
7) ExceptionCardImpress
DwellTime
2000 2000 [0 – 10000]
8) ExceptionCardImpress
PositionOffset1
2000 2000 [0 – 4000]
