DataCard CR805 Installation And Administrator's Guide

CR805 Retransfer Card Printer Instrallation and Administrator’s Guide A-19
Laminator Replacement Parts
Laminator Cartridges
The green L1 and orange L2 cartridges hold the laminator
overlay material. They are used in the optional CLM laminator
only.
Impresser Die
Contact Entrust Datacard to special-order a new die for your impresser. The
die must be installed by an authorized Entrust Datacard service provider.
Laminator Power Supplies
The laminator power supplies are rated as follows:
 Laminator with L1 only:
 Input: 100–240V, 47–63Hz, 2.2A
 Output: 24V, 3.75A, 90W
 Laminator with L1 and L2:
 Input: 100–240V, 47–63Hz, 2.2A
 Output: 24V, 6.6A, 160W
Laminator power supplies are self-adjusting within the rated input voltage
Power Cords
Refer to “Power Cords” on page 116 for a list of available power cords.
