CR805 Retransfer Card Printer Installation and Administrator’s Guide 27
Install a Large Output Hopper
You can install a large output hopper on the printer, depending on your requirements.
The standard output hopper included with the printer holds approximately 25 0.030 in.
(0.762 mm) cards. The printer also can be used with an optional large output hopper that holds
up to 125 cards. The large output hopper consists of a 125-card replacement hopper and an
extended pedestal base.
Do the following to install the large output hopper.
1. Remove the standard output hopper from the printer.
Pull the hopper straight out from the printer.
2. Place the printer on the extended pedestal base. Make
sure that it is lined up correctly on the pedestal.
The large output hopper can be installed only on single-hopper printers.
