DeDietrich AMC 15 User Manual

13.3 Spare parts list
Tab.83 Casing
Markers Code no. Description 15 25 25/28
MI
35
1001 7665189 Magnets x x x x
1001 7703802 Casing Front Panel x x x x
1002 7700066 Cover Drop Down x x x x
1005 7665192 Seal Cover Frame / HMI x x x x
1006 S101403 Stud Quarter Retainer x x x x
1007 S101253 Boiler Light x x x x
Tab.84 Heat exchanger and burner
Markers Code no. Description 15 25 25/28
MI
35
2001 7689674 Heat Exchanger 28kW x x x
2001 7689714 Heat Exchanger 40 kW x
2002 S100894 Condensate Collector 253 mm x x x
2002 S101181 Condensate Collector 338 mm x
2003 7703779 Energy-efficient pump x x x x
2004 S100905 Siphon Assembly x x x x
2005 7665244 Piping Set Flow and Return x x x x
2006 S100854 Flue Gas Exhaust Pipe Ø 80 (28 kW) x x x
2006 S101199 Flue Gas Exhaust Pipe Ø 80 (40 kW) x
2007 S100906 Sealing Ring Siphon x x x x
2008 S59586 Hairpin Spring 18 mm (10 Pcs.) x x x x
2009 7689676 Vibration Silencer x x x x
2010 7673034 O-ring 18x2.8 MOS2 (10x) x x x x
2011 7623837 Sensors Set Double NTC 10K (1x) and NTC 10K(2x) x x x x
2012 S100890 Electrode Ignition/Ionisation x x x x
2013 S59118 Glass Inspection Set x x x x
2014 S62105 Gasket For Electrode (10 Pcs.) x x x x
2015 S48950 Screw M4 x 10 (50 Pcs.) x x x x
2016 S100880 Gasket For Burner 212 x 84 mm x x x
2016 S101196 Gasket For Burner 40 kW x
2017 7669770 Air Vent x x x x
2018 S58730 O-Ring 17 x 4 (10 Pcs.) x x x x
2019 S100891 Hose silicone 8 x 4 x 715 mm x x x x
2020 S100888 Gasket Heat Exchanger-Condensate Collector x x x
2020 S101179 Gasket Heat Exchanger-Condensate Collector x
2021 S100892 Gasket Flue Gas Discharge-Condensate Col x x x x
2022 S100855 Sealing Ring Ø 80 (5 Pcs.) x x x x
2023 S100850 Cap Measure Point Flue Gas Pipe x x x x
2024 S100901 Fixing Strip Heat Exchanger x x x x
2025 S100838 Transformer Ignition Incl. Electrode x x x x
2026 7665193 Grommet Siphon x x x x
2027 S100765 Flue Gas Discharge Adapter 60/100 x x x x
2028 S62232 Screw Cap Flue Gas Measure Point (5 Pcs.) x x x x
2029 S62233 Plug For Air Inlet Measure Point (5 Pcs.) x x x x
2031 S100197 Airvent Pump x x x x
2032 S56155 Gasket 23.8 x 17.2 x 2 mm x x x x
2033 S100814 Clip 10.3 (5 Pcs.) x x x x
2034 S62586 O-Ring Ø 9.19 x 2.62 (10 Pcs.) x x x x
13 Spare parts
7686707 - v.01 - 06092018 AMC 127
