DeDietrich AMC 15 User Manual

Code Text display Description Range
GM011 Power setpoint Power setpoint in % of maximum 0 % - 100 %
GM012 Release Input Release signal for the CU 0 = No
1 = Yes
GM013 Blocking Input Blocking input status 0 = Open
1 = Closed
2 = Off
GM025 STB status High limit status (0 = open, 1 = closed) 0 = Open
1 = Closed
2 = Off
GM027 Flame Test Active Flame test 1=active, 0=inactive 0 = Inactive
1 = Active
GM044 ControlledStopReason Possible reason for Controlled Stop 0 = None
1 = CH Blocking
2 = DHW Blocking
3 = Wait for burner
4 = TFlow > absolute max
5 = TFlow > start temp.
6 = Theat exch. > Tstart
7 = Avg Tflow > Tstart
8 = TFlow > max setpoint
9 = T difference too big
10 = TFlow > stop temp.
11 = Avg Tflow > Tstop
PM002 CH Setpoint External winning Central Heating
setpoint
0 °C - 250 °C
PM003 ChTflowAverage Actual average flow temperature -25 °C - 150 °C
9.6.3 Status and sub-status
The status and sub-status are only shown if applicable.
Tab.77 Status numbers
Status Description
0 Standby
1 Heat Demand
2 Burner Start
3 Burning CH
4 Burning Dhw
5 Burner Stop
6 Pump Post Run
7 Cooling Active
8 Controlled Stop
9 Blocking Mode
10 Locking Mode
11 Load test min
12 Load test CH max
13 Load test DHW max
15 Manual Heat Demand
16 Frost Protection
17 DeAiration
18 Control unit Cooling
19 Reset In Progress
20 Auto Filling
21 Halted
22 Forced calibration
23 Factory test
9 Settings
96 AMC 7686707 - v.01 - 06092018
