6.2.2 Positioning the boiler
1. Remove the black protective strip on the underside of the boiler.
2. Remove the dust caps from all of the hydraulic inlets and outlets on
the boiler.
Caution
The valve of the filling loop must be closed.
3. Fit a fibre gasket to each joint on the valve plate.
4. Position the boiler above the mounting frame. Gently lower the boiler.
5. Tighten the valve nuts on the boiler.
Fig.15 Removing boiler protection
AD-0001380-02
Fig.16 Fitting gaskets
AD-0001381-02
Fig.17 Fitting the boiler
AD-3001203-01
6 Installation
7686707 - v.01 - 06092018 AMC 25
