9.2.1 CU-GH08 control unit settings
Important
All tables show the factory setting for the parameters.
The tables also list parameters that are only applicable if the
boiler is combined with other equipment such as an outdoor
sensor or automatic refill device.
Tab.60
On > > Installation Setup > CU-GH08 > CIRCA ( Direct zone ) > Parameters, counters, signals > Parameters
Code Text display Description Adjustment range 10 15 25 25/28
MI
35
Zone friendly
Name
Friendly Name of the user
zone
0 0 0 0 0
ZoneStartTimeHol
iday
Zone Start Time holiday
Mode
- - - - -
ZoneEndTime
Holiday
Zone End Time of holiday
Mode
- - - - -
ZoneEnd Change
Mode
Zone End Time of change
Mode
- - - - -
CP000 MaxZoneTFlowSe
tpoint
Maximum Flow Temperature
setpoint zone
0 °C - 90 °C 80 80 80 80 80
CP010 Tflow setpoint
zone
Zone flow temperature
setpoint, used when the
zone is set to a fixed flow
setpoint.
0 °C - 90 °C 80 80 80 80 80
CP020 Zone Function Functionality of the zone 0 = Disable
1 = Direct
1 1 1 1 1
CP060 RoomT. Holiday Wished room zone
temperature on holiday
period
5 °C - 20 °C 6 6 6 6 6
CP070 MaxReducedRoo
mT.Lim
Max Room Temperature
limit of the circuit in reduced
mode, that allows switching
to comfort mode
5 °C - 30 °C 16 16 16 16 16
CP080 User T.Room
Activity
Room setpoint temperature
of the user zone activity
5 °C - 30 °C 16 16 16 16 16
CP081 User T.Room
Activity
Room setpoint temperature
of the user zone activity
5 °C - 30 °C 20 20 20 20 20
CP082 User T.Room
Activity
Room setpoint temperature
of the user zone activity
5 °C - 30 °C 6 6 6 6 6
CP083 User T.Room
Activity
Room setpoint temperature
of the user zone activity
5 °C - 30 °C 21 21 21 21 21
CP084 User T.Room
Activity
Room setpoint temperature
of the user zone activity
5 °C - 30 °C 22 22 22 22 22
CP085 User T.Room
Activity
Room setpoint temperature
of the user zone activity
5 °C - 30 °C 20 20 20 20 20
CP130 T.OutdoorToZone Assigning the outdoor
sensor to zone …
0 - 4 0 0 0 0 0
CP200 Manu
ZoneRoomTempS
et
Manually setting the room
temperature setpoint of the
zone
5 °C - 30 °C 20 20 20 20 20
CP210 Zone HCZP
Comfort
Comfort footpoint of the
temperature of heat curve of
the circuit
15 °C - 90 °C 15 15 15 15 15
CP220 Zone HCZP
Reduced
Reduced footpoint of the
temperature of heat curve of
the circuit
15 °C - 90 °C 15 15 15 15 15
CP230 Zone Heating
Curve
Heating curve temperature
gradient of the zone
0 - 4 1.5 1.5 1.5 1.5 1.5
9 Settings
7686707 - v.01 - 06092018 AMC 85
