Sub-status Description
73 HPFlowOverTMax
74 SourcePumpPostRun
75 HumiditySensorStopHP
76 WaterFlowStopHP
78 HumidityInt.Setpoint
79 HP&BackupRelieved
80 HPRelievedForCooling
81 OutsideTempStopHP
82 HeatPumpOffOverLimit
83 DeAirPumpOn&ValveCH
84 DeAirPumpOn&ValveDhw
85 DeAirPumpOff&ValveCH
86 DeAirPumpOff&ValvDhw
88 BLInputBackupLimited
89 HPLimited
90 Backup&HPLimited
91 BLInputLowTariff
92 PV-WithHP
93 PV-WithHP&Bckp
94 BLInputSmartGrid
95 WaitingForWaterpress
96 NoProducerAvailable
102 FreeCoolingPumpOff
103 FreeCoolingPumpON
104 SourcePumpPreRunning
105 Calibration
200 Initialising Done
201 Initialising Csu
202 Init. Identifiers
203 Init.BL.Parameter
204 Init. Safety Unit
205 Init. Blocking
254 StateUnknown
255 SuOutOfResetsWait1Hr
9.7 Resetting or restoring settings
9.7.1 Resetting the configuration numbers CN1 and CN2
The configuration numbers must be reset when indicated by an error
message or when the control unit has been replaced. The configuration
numbers can be found on the data plate of the appliance.
A Select the control unit
B Extra information
C Configuration numbers
1. Press the button.
2. Select Advanced Service Menu > Set Configuration Numbers.
3. Select the control unit you want to reset.
4. Select and change the CN1 setting.
5. Select and change the CN2 setting.
6. Select Confirm to confirm the changed numbers.
Fig.92 Configuration numbers
AD-3000935-01
A B
C
9 Settings
98 AMC 7686707 - v.01 - 06092018
