Symbol Explanation
Hot-air heater
Swimming pool
6.7.2 Factory configuration of circuits
From the factory, the different circuits are configured as shown in the
table. You can modify this configuration and adapt it to the needs of your
installation.
Tab.26 Factory circuit configuration
Circuit Circuit type
CIRCA Direct heating circuit
CIRCB Circuit with 3 way valve
CIRCC Circuit with 3 way valve
6.7.3
Boiler settings with SCB-10 control
When the boiler is fitted with the SCB-10 control board the following boiler
parameter(s) at installer level must be checked and adjusted, if necessary:
Tab.27 Installation Setup > CU-GH08 > CIRCA > Parameters, counters, signals > Parameters
Code Display text Description Range Adjust
ment
CP020 Zone Function Functionality of the zone 0 = Disable
1 = Direct
2 = Mixing Circuit
3 = Swimming pool
4 = High Temperature
5 = Fan Convector
6 = DHW tank
7 = Electrical DHW
8 = Time Program
9 = ProcessHeat
10 = DHW Layered
11 = DHW Internal tank
31 = DHW FWS EXT
0
Tab.28 Installation Setup > CU-GH08 > Gas fired appliance > Parameters, counters, signals > Parameters
Code Display text Description Range Adjust
ment
AP102 Boiler Pump function Configuration of the boiler pump as
zone pump or system pump (feed
lowloss header)
0 = No
1 = Yes
0
Tab.29 Installation Setup > CU-GH08 > Tank DHW > Parameters, counters, signals > Parameters
Code Display text Description Range Adjust
ment
DP007 Dhw 3wv Standby Position of three way valve during
standby
0 = CH position
1 = DHW position
0
For the hydraulic connections as shown, where some parameters must be
adjusted, the parameter settings are arranged in three levels:
1. End user level
6 Installation
7686707 - v.01 - 06092018 AMC 47
