278 Understanding the Tool Box Menus
NOTE: Values marked by an asterisk (*) are the factory default menu settings.
Chart Print
Purpose:
To print various charts that can be used for diagnosis of the printer. The chart is
printed to A4 or letter size paper.
Values:
Machine Check
Purpose:
To check the operation of the printer components.
Values:
Pitch Configuration Chart Prints full halftone pages for yellow, magenta, cyan, and
black. Also prints pages to check the pitch. A total of
five pages are output.
Ghost Configuration Chart Prints a chart to check for ghost printing. One page is
printed.
4 Colors Configuration
Chart
Bands of yellow, magenta, cyan, and black are printed
with varying density. One page is printed.
MQ Chart Prints charts to check for the binding in A4 or Letter.
Alignment Chart Prints a chart to check for proper alignment of the print
image on the paper. One page is printed.
Drum Refresh
Configuration Chart
Prints a chart to check the light fatigue of the drum
cartridge.

Dell 2150cn Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Internal memory	256 MB
Processor frequency	400 MHz
Maximum internal memory	750 MB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	501 sheets
Multi-Purpose tray input capacity	1 sheets
Maximum duty cycle	40000 pages per month
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4
Network ready	-
Networking features	Gigabit Ethernet
Supported media weight(s)	60 - 216 g/m²
Compatible operating systems	Microsoft Windows 7/Vista/2008/XP/2003 Mac OS: 10.3.9+/10.4.11+/10.5/10.6 Linux: SUSE Linux 10/Red Hat Linux 5
Compliance industry standards	IEEE 802.3/802.3u/802.3ab
Power consumption (printing)	- W
Display	LCD

Weight and Dimensions

Dimensions (WxDxH)	400 x 406 x 412.8 mm
