Dell 2150cn - Direct Connection Setup

Installing Printer Drivers on the Windows Computers 95
FILE LOCATION: C:\Users\fxstdpc-
admin\Desktop\0630_UG??\Mioga_SFP_UG_FM\Mioga_SFP_UG_FM\section10.fm
DELL CONFIDENTIAL – PRELIMINARY 9/13/10 - FOR PROOF ONLY
Click Start  All Programs  Accessories  Run , enter
D:\setup_assist.exe (where D is the CD drive letter) in the Run dialog
box, and then click OK .
Direct Connection Setup
For installing PCL printer driver
1 In the Easy Setup Navigator window, click Software Installation to launch
the installation software.
2 Select Personal Installation , and then click Next .
3 Select the model name of your printer, and then click Next .
4 Follow the on-screen instructions to connect the computer and the printer
with a USB cable, and then turn the printer on.
The Plug and Play installation starts and the installation software proceeds to
the next page automatically.
NOTE: If the installation software does not automatically proceed to the
next page, click Install.
5 Select either Typical Installation or Custom Installation from the
installation wizard, and then click
Install . If you select Custom Installation ,
you can select the specific software you want to install.
6 Click Finish to exit the wizard when the Congratulations! screen appears.
To print a test page, click
Print Test Page .
USB Printing
A personal printer is a printer connected to your computer or a print server using
a USB. If your printer is connected to a network and not your computer, see
"Network Connection Setup."
For installing XML Paper Specification (XPS) printer driver
NOTE: XPS driver is supported on the following operating systems: Windows
Vista, Windows Vista 64-bit Edition, Windows Server 2008, Windows Server 2008
64-bit Edition, Windows Server 2008 R2, Windows 7, and Windows 7 64-bit
Edition.
Windows Vista or Windows Vista 64-bit Edition
