Dell 2150cn User Manual

416 Clearing Jams
FILE LOCATION: C:\Users\fxstdpc-
admin\Desktop\0630_UG??\Mioga_SFP_UG_FM\Mioga_SFP_UG_FM\section27.fm
DELL CONFIDENTIAL – PRELIMINARY 9/13/10 - FOR PROOF ONLY
NOTICE: Do not use excessive force on the tray. Doing so could damage the tray
or the inside of the printer.
Clearing Paper Jams From the Standard 250-
Sheet Tray
NOTICE: Protect the drums of the Print Head Device (PHD) against bright light.
If the front cover remains open for more than three minutes, print quality may
deteriorate.
NOTE: To resolve the error displayed on the operator panel, you must clear all
print media from the print media path.
1 Pull the standard 250-sheet tray out of the printer carefully. Hold the tray
with both hands, lift the front slightly, and remove it from the printer.

Dell 2150cn Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Internal memory	256 MB
Processor frequency	400 MHz
Maximum internal memory	750 MB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	501 sheets
Multi-Purpose tray input capacity	1 sheets
Maximum duty cycle	40000 pages per month
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4
Network ready	-
Networking features	Gigabit Ethernet
Supported media weight(s)	60 - 216 g/m²
Compatible operating systems	Microsoft Windows 7/Vista/2008/XP/2003 Mac OS: 10.3.9+/10.4.11+/10.5/10.6 Linux: SUSE Linux 10/Red Hat Linux 5
Compliance industry standards	IEEE 802.3/802.3u/802.3ab
Power consumption (printing)	- W
Display	LCD

Weight and Dimensions

Dimensions (WxDxH)	400 x 406 x 412.8 mm
