Dell 2150cn User Manual

82 Connecting Your Printer
To connect the printer to the network, connect one end of an Ethernet cable into
the Ethernet port on the rear of the printer, and the other end to a LAN drop or
hub. To setup a wireless connection, insert the wireless adapter into the wireless
adapter socket on the back of the printer.
For a wireless connection, see "Installing the Optional Wireless Adapter."
NOTE: To use the wireless adapter, be sure to disconnect the network cable.
Turning on the Printer
CAUTION: Do not use extension cords or power strips.
CAUTION: The printer should not be plugged into a UPS (Uninterruptible Power
Supply) system.
1 Connect the power cable to the power connector on the rear of the printer,
and then to a power source.
2 Turn on the printer. When the printer is connected via a USB cable, the USB
driver is automatically installed.
1 Ethernet port

Dell 2150cn Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Internal memory	256 MB
Processor frequency	400 MHz
Maximum internal memory	750 MB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	501 sheets
Multi-Purpose tray input capacity	1 sheets
Maximum duty cycle	40000 pages per month
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4
Network ready	-
Networking features	Gigabit Ethernet
Supported media weight(s)	60 - 216 g/m²
Compatible operating systems	Microsoft Windows 7/Vista/2008/XP/2003 Mac OS: 10.3.9+/10.4.11+/10.5/10.6 Linux: SUSE Linux 10/Red Hat Linux 5
Compliance industry standards	IEEE 802.3/802.3u/802.3ab
Power consumption (printing)	- W
Display	LCD

Weight and Dimensions

Dimensions (WxDxH)	400 x 406 x 412.8 mm
