Dell 2150cn User Manual

46 Installing Optional Accessories
If the printer information is not updated automatically after clicking Get
Information from Printer, follow these steps:
1
Click the Options tab, and then select Memory Capacity in the Items list
box.
2 Select the total amount of the installed printer memory for the memory
capacity setting.
3 Click Apply , and then click OK .
4 Close the Printers and Faxes (, Printers , or Devices and Printers ) dialog
box.
Installing the Optional 250-Sheet Feeder
CAUTION: If you install the optional 250-sheet feeder after setting up the printer,
be sure to turn off the printer, unplug the power cable, and disconnect all cables
from the back of the printer before starting this task.
1 Ensure that the printer is turned off, and then disconnect all cables from the
back of the printer.
2 Remove all packaging from the optional 250-sheet feeder.
3 Place the optional 250-sheet feeder in the location that the printer is located.
Windows Server 2008/
Server 2008 x64
1 Click Start  Control Panel  Printers .
2 Right-click the printer icon of the Dell 2150cn Color Printer
and select Properties .
3 Click the Options tab, and then select Get Information from
Printer .
4 Click Apply , and then click OK .
5 Close the Printers dialog box.
Windows XP/XP x64/
Windows Server 2003/
Windows Server 2003
x64
1 Click start  Printers and Faxes .
2 Right-click the printer icon of the Dell 2150cn Color Printer
and select Properties .
3 Click the Options tab, and then select Get Information from
Printer .
4 Click Apply , and then click OK .
5 Close the Printers and Faxes dialog box.

Dell 2150cn Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Print speed (black, normal quality, A4/US Letter)	23 ppm
Internal memory	256 MB
Processor frequency	400 MHz
Maximum internal memory	750 MB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	501 sheets
Multi-Purpose tray input capacity	1 sheets
Maximum duty cycle	40000 pages per month
Maximum print size	216 x 297 mm
Paper tray media types	Envelopes, Labels, Plain paper, Recycled paper
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4
Network ready	-
Networking features	Gigabit Ethernet
Supported media weight(s)	60 - 216 g/m²
Compatible operating systems	Microsoft Windows 7/Vista/2008/XP/2003 Mac OS: 10.3.9+/10.4.11+/10.5/10.6 Linux: SUSE Linux 10/Red Hat Linux 5
Compliance industry standards	IEEE 802.3/802.3u/802.3ab
Power consumption (printing)	- W
Display	LCD

Weight and Dimensions

Dimensions (WxDxH)	400 x 406 x 412.8 mm
