LED Location State Description
Blue and amber
alternating at one
second intervals
Node in Service Mode.
Off No fault has occurred, normal operation.
Node power Green Node is on (main power).
Green blinking Node is initializing a serial over LAN session
(Standby Mode).
Off Node is off.
Unsafe to remove White Do not remove the node. Improper removal
could cause data loss.
Off Safe to remove the embedded module when
the embedded module has been properly
prepared.
Power down the node
Power down the node as described in Power control procedures.
Remove an embedded module
Steps
1. Label and disconnect all cables that are attached to the embedded module.
CAUTION:
Do not pull the node from the base enclosure. Pulling the node from the base enclosure disrupts the
system cache.
2. Push the orange tab on the embedded module to release the lever.
Base enclosure service procedures
41
