Removing a faulted LCC
Prerequisites
Identify the faulted LCC by it amber fault LED.
Figure 125. LCC fault LED
About this task
NOTE: The DAE must have at least one LCC installed while the enclosure is powered up; do not remove both LCCs while
AC power is on.
Steps
1. Attach an ESD wristband to your wrist and the enclosure.
2. Remove each cable connected to the LCC by gently pulling the connector latches to release the cable from the connector.
Note where the cables connect to the LCC because you will reconnect them later.
Figure 126. Disconnecting an LCC cable
3. Remove the LCC:
88
Expansion enclosure service procedures
