Section 1: System installation and design
Order code Description Dimensions (mm)
CIOP4 Addressable 4 Way Mimic Relay Board (4 In, 4 Out) 180H x 254W x 90D
CIOP8 Addressable 8 Way Mimic Relay Board (4 In, 8 Out) 180H x 254W x 90D
CIOP-7273 Addressable Door Release Module 130H x 180W x 60D
CIO351 Addressable 3 Channel I/O Unit (Reset on Reset) 130H x 180W x 60D
CIO351S Addressable 3 Channel I/O Unit (Reset on Silence) 130H x 180W x 60D
CIO351SST Addressable 3 Channel I/O Unit (Triple Address) 130H x 180W x 60D
400008FIRE-0022X Addressable Micro Input Module (MCIM) 65H x 35W x 18.5D
400010FIRE-0024X Addressable Micro Output Module (MCOM) 65H x 35W x 18.5D
400011FIRE-0025X
Addressable Micro Output Module
(MCOM-R, Reset Pulse)
65H x 35W x 18.5D
400012FIRE-0026X
Addressable Micro Output Module
(MCOM-S, Sounder ID)
65H x 35W x 18.5D
MIU872 Addressable Micro Zone Monitor Unit 65H x 35W x 18.5D
MAR724 Heavy Duty Relay 88H x 147W x 57D
ZPCB2252-MML Addressable Master LED MIMIC 190H x 350W x 75D
ZPCB2252-MSL Addressable Slave LED MIMIC 190H x 350W x 75D
Equipment compatibility
Sensors
Loop wired sensors must be of the Eaton soft addressed analogue type. Eaton
conventional detectors can be connected via a Zone Monitor Unit or Shop Unit
interface. The connection of other detector types via a Zone Monitor Unit or Shop
Unit interface is not recommended,
Call points
Loop wired call points must be the Eaton series soft addressed analogue type,
Eaton series conventional callpoints can be connected via a Zone Monitor Unit or
Shop Unit interface.
The connection of other callpoint types via a Zone Monitor Unit or Shop Unit
interface is not recommended,
Sounders
Loop powered addressable sounders must be of the Eaton series soft addressed
analogue type.
Conventional sounders can also be connected either to the conventional sounder
circuits at the panel or to the loop via an addressable sounder controller interface
providing they meet the following:
