Section 3: Panel controls & indicators
Panel operation
The Panel is operated via a backlit touch screen. The default fire screen is shown
below. From this screen all the panels functions can be operated. The first time you
touch the screen the backlight will illuminate the panel.
Pressing a field will highlight it and forward to the next screen as shown below.
Supervisor
FRE Off
Pre Alarm
0
Faults
0
System Healthy
XX Zones Active
Fires
0
Disabled
/Test
Mute buzzer
11:01:35
Supervisor
FRE Off
Pre
A
larms 0
Faults
0
System Healthy
10 Zones Active
Tuesday
dd-mm-yyyy
16:25.25
BST On
Fires
1
Disabled
/ Test
Disabled
/ Test
Supervisor
FRE Off
Pre
A
larms 0
Faults
0
Tuesday
Dd-mmm-yyy
16:25.25
BST On
First Fire
Total Fires= 1
Meeting Room 1, Building 1, 1st floor
Loop: 1, Zone: 2, Type: Optical (150)
Fires
1
Print All
Help
Touch the screen here
to view details
