User manual SEFELEC 5x Series 153 v1.06

CONNECTIONS

The input-output signals are accessible on the rear face of the device on terminals C6, C7 and

Note:

Every terminal has

a mechanical coding

Connector C6

Connector C7

Connector C8

IN_OUT_0-10V_0

Type:

IN_OUT_0-10V_1

MESDCH

GND10V

IN_0-10V_3

+24VDC

(1)

COMOUT

COMIN

CTRLOUT

SR0

CTRLIN

PLCFAIL

SR1

EOT

SR2

PLCPASS

SR3

ERROR

IN_0-10V_2

GND

(2)

(1) Unregulated internal 24VDC power supply protected by a resettable PTC fuse, maximum

current 1 A

(2) NC = Not Connected
