Eaton SEFELEC 56-D User Manual

User manual SEFELEC 5x Series 18 v1.06
SPECIFICATIONS
OVERVOLTAGE CATEGORY
Supply to the device by a CAT II mains network
POLLUTION DEGREE
Pollution 2: occasional conductive pollution by condensation only.
SAFETY CLASS
Class I: device connected to the protective ground by the power cord, Ground < 3 Ω, power line
disturbance < 10 ms
ENVIRONMENT
Regular dusting of the device is recommended. For optimal operation of the electronics, an am-
bient temperature range of 15°C to 35°C is required. The air inlets of the device must be clear.
The device must be used indoors, in a horizontal position or tilted on its legs.
GENERAL CHARACTERISTICS
Mains
100-240VAC ±10% 50/60Hz single phase
230VAC ±10% 50/60Hz single phase (SEFELEC 506-H/D/S)
Power
950 VA max.
Mains protection
Double timed fuse T10AH 250 V
Temperature Range
Storage
Use
-10°C to +60°C
0°C to +45°C
Specified accuracy 1/2 hour after of powering and HR < 50%
Altitude
Up to 2,000 meters
Relative humidity
80% max. @ 31°C - linear decrease to 50%RH @40°C
Sound pressure
Max. 80 dBA @ 1 metre
SEFELEC 56-H/D
SEFELEC 506-H/D
SEFELEC 56/506-S
SEFELEC 1000-M/32-C
Ground
15 kg
21 kg *
27 kg *
* 2 people required for handling weights > 18 kg
Dimensions
Height
Width
Depth
131 mm
440 mm
455 mm

Eaton SEFELEC 56-D Specifications

General

Brand	Eaton
Model	SEFELEC 56-D
Category	Test Equipment
Language	English
