User manual SEFELEC 5x Series 33 v1.06
COMMISSIONING
NOTE
The device must be used indoors, in a horizontal position or tilted on its
legs. The hardware must be installed on a horizontal plane that supports
its weight, in a space that is sufficiently light and is not
humid. The air
inlets of the device must be cle
ar.
WARNING
Danger of electric shock!
• Commissioning, use and maintenance of the equipment must be car-
ried out by qualified personnel.
• All precautions related to the use of equipment connected to the elec-
trical network must be taken when using it.
•
In particular, it is absolutely necessary to connect the equipment to the
ground by the power cord and via the ground pin provided for this
purpose on rear face of the unit (see paragraph 20.1 item Z2)
• Always be sure that the high voltage light is turned off before connect-
ing or disconnecting an element to be tested.
DELIVERY CONTENT
On delivery of the measurement device, the packaging box must contain the following articles as
standard:
• 1 measuring device from the SEFELEC 56/506-H/D/S, 1000-M or 32-C range
• 1 AC Power Cord 2P+G, 16 A of length 1.5 m
• 4 10-pin plugs of the screw terminal type provided with a green cover
• 1 complete Operating Manual of the device (the paper version or accessible via a link on
our Internet site)
• 1 manual of safety rules for high-voltage tests
• 1 CE certificate of conformity (included at the end of this manual)
And depending on your order:
• The measurement accessories
• WINPASS_MX software
• 1 audit report with the measurement readings.
If any item is missing, contact EATON. See chapter entitled After-sales service.
