User manual SEFELEC 5x Series 161 v1.06
IEEE488-2 (GPIB) INTERFACE
Note:
The IEEE488-2 function must be selected in the configuration menu,
interface line: IEEE488 Enter the value of the address of the device
tween 0 and 30.
SEFELEC test and measurement instruments can be equipped with an IEEE-488 interface. It
enables the integration of all the instruments of the range in an automatic test or measure-
ment system whether it is intended for production control or entry control.
The interface is accessible through a connector on the rear panel of the device.
The implementation of the safety loop is essential. The control of the device
and therefore the generation of a dangerous voltage by IEEE488-2 can be done from a
point where visual inspection of the device is not possible.
