11 ALARM SUMMARY TABLE (Note that some alarms might not be valid for your appliance)
Alarm Description Possible fault Machine status/action Reset
E00
E11
Water fill difficulty during washing
Tap closed or water pressure too low; Drain pipe improperly
positioned; Water fill solenoid valve faulty; Leaks from water circuit on
pressure switch; Pressure switch faulty; Wiring faulty; Main PCB
faulty.
Cycle is paused with door locked. START/RESET
E13
Water leaks
Drain pipe improperly positioned; Water pressure too low;
Water fill solenoid valve faulty; Water circuit on pressure switch is
leaking/clogged; Pressure switch faulty.
Cycle is paused with door locked. START/RESET
E21
Drain difficulty during washing
Drain pipe kinked/clogged/improperly positioned; Drain filter
clogged/dirty; Wiring faulty; Pressure switch faulty; Drain pump rotor
blocked; Drain pump faulty; Main PCB faulty.
Cycle paused
(after 2 attempts).
START
ON/OFF
RESET
E23
Faulty triac for drain pump Wiring faulty; Drain pump faulty; Main PCB faulty.
Safety drain cycle - Cycle stops with
door open.
RESET
E24
Drain pump TRIAC “sensing” circuit
faulty.
Main circuit board faulty.
Safety drain cycle - Cycle stops with
door unlocked.
RESET
E31
Malfunction in electronic water level
sensor
Wiring; Faulty water level sensor; Main PCB. Cycle stops with door locked. RESET
E32
Calibration error of the electronic
pressure switch
Drain pipe kinked/clogged/improperly positioned; Solenoid valve
faulty; Drain filter clogged/dirty; Drain pump faulty; Leaks from
pressure switch hydraulic circuit; Pressure switch faulty;
Wiring; main PCB.
Cycle paused. START/RESET
E35
Overflow
Water fill solenoid valve faulty; Leaks from water circuit on pressure
switch; Wiring faulty; Pressure switch faulty; Main PCB faulty.
Cycle interrupted. Safety drain cycle.
Drain pump continues to operate (5 min.
on, then 5 min. off. etc.).
RESET
E38
Internal pressure chamber is
clogged (water level does not
change for at least 30 sec. of drum
rotation)
Motor belt broken; Water circuit on pressure switch clogged. Heating phase is skipped. RESET
E41
Door open
Check whether the door is closed properly;
Wiring faulty; Door safety interlock faulty;
Main circuit board faulty.
Cycle paused. START/RESET
E42
Problems with door lock
Wiring faulty; Door safety interlock faulty;
Electrical current leak between heating element and ground;
Main PCB faulty.
Cycle paused. START/RESET
E43
Faulty triac supplying power to door
delay system
Wiring faulty; Door safety interlock faulty;
Main circuit board faulty.
(Safety drain cycle)
Cycle blocked.
RESET
E44
Faulty sensing by door delay
system
Main circuit board faulty.
(Safety drain cycle)
Cycle blocked.
RESET
E45
Faulty sensing by door delay
system triac
Main circuit board faulty.
(Safety drain cycle)
Cycle blocked.
RESET

Electrolux WE170P Specifications

General

Door hinge	Left
Water fill	Cold, Hot
Drum volume	67 L
Control type	Buttons, Rotary
Display type	LCD
Loading type	Front-load
Drum material	Stainless steel
Product color	Gray
Built-in display	Yes
Appliance placement	Freestanding
Dispenser tray type	3-way
Drying capacity	- kg
Cycle time (max)	210 min
Washing capacity	8 kg
AquaStop function	No
Spin-drying class	-
Cycle time washing	70 min
Maximum spin speed	- RPM
Minimum spin speed	1400 RPM
Noise level (spin)	75 dB
Noise level (wash)	49 dB
Noise level (drying)	- dB
Number of washing programs	16
Cycle time (quick washing program)	20 min
Connected load	2000 W
AC input voltage	230 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Water consumption per cycle	47 L
Water consumption washing per cycle	65 L
Energy consumption washing per cycle	0.7 kWh
Water consumption washing & drying per cycle	- L
Energy consumption washing & drying per cycle	- kWh

Weight and Dimensions

Depth	624 mm
Width	597 mm
Height	850 mm
Weight	80.5 g
Package depth	701 mm
Package width	630 mm
Package height	900 mm
Package weight	82 g
Depth with door open	1066 mm
