Electrolux WE170P Service Manual

56
11.1 Alarm codes for appliance with external liquid supply system
Alarm
code
Alarm description Fault condition Possible fault
Machine
action/status
Reset key
E9A
DET_DOSING_ABS_AL
External liquid supply system configured but communication failure
(before payment).
Wiring defective
External liquid supply system defective
MB defective
No power supply to sat
Cycle blocked OFF/ON
EF9
DET_DOSING_COM_AL
External liquid supply system configured but communication failure
(after payment).
Wiring defective
External liquid supply system defective
MB defective
No or wrong power supply to sat
No actions OFF/ON
11.2 Detailed description of alarm codes
11.2.1 E9A - External liquid supply system configured but communication failure (before payment)
The user has not yet paid and there are communication problems in between External liquid supply system board and Motherboard.
Problems could be due to Hardware (problems on connectors for example disconnection, on satellite or mother board), due to disturbs (burst on wiring) or satellite
unplugged from power supply.
The alarm appears after 5 seconds of missing communication after which the communication is interrupted for 35 seconds. Then the Motherboard retries to restore the
connection and, if the problem remains, disconnects again.
This alarm is displayed on the user interface using the format “E” + “9”(alarm family digit) + “0”.
When the alarm is set the machine is blocked. To clear the alarm is necessary to switch off the machine.
11.2.2 EF9 — External liquid supply system configured but communication failure (after payment)
The user has already paid and there are communication problems in between External liquid supply system board and Motherboard.
Problems could be due to Hardware (problems on connectors for example disconnection, on satellite or mother board), due to disturbs (burst on wiring) or satellite
unplugged from power supply.
The alarm appears after 5 seconds of missing communication after which the communication is interrupted for 35 seconds. Then the Motherboard retries to restore the
connection and, if the problem remains, disconnects again.
The alarm is not displayed.
No action is executed when alarm is detected. To clear the alarm is necessary to switch off the machine.

Electrolux WE170P Specifications

General

Door hinge	Left
Water fill	Cold, Hot
Drum volume	67 L
Control type	Buttons, Rotary
Display type	LCD
Loading type	Front-load
Drum material	Stainless steel
Product color	Gray
Built-in display	Yes
Appliance placement	Freestanding
Dispenser tray type	3-way
Drying capacity	- kg
Cycle time (max)	210 min
Washing capacity	8 kg
AquaStop function	No
Spin-drying class	-
Cycle time washing	70 min
Maximum spin speed	- RPM
Minimum spin speed	1400 RPM
Noise level (spin)	75 dB
Noise level (wash)	49 dB
Noise level (drying)	- dB
Number of washing programs	16
Cycle time (quick washing program)	20 min
Connected load	2000 W
AC input voltage	230 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Water consumption per cycle	47 L
Water consumption washing per cycle	65 L
Energy consumption washing per cycle	0.7 kWh
Water consumption washing & drying per cycle	- L
Energy consumption washing & drying per cycle	- kWh

Weight and Dimensions

Depth	624 mm
Width	597 mm
Height	850 mm
Weight	80.5 g
Package depth	701 mm
Package width	630 mm
Package height	900 mm
Package weight	82 g
Depth with door open	1066 mm
