Electrolux WE170P Service Manual

Technical Support - DMM 59/80 599 74 98-60 Rev.00
Remove the connectors protection.
Pull out the connectors positioned beside the board.
Pull out the other connectors, taking care as they are retained by hooks.
12.2.2 Solenoid valve
Remove the worktop.
Disconnect the connectors.
Pull out the pipes which connect the solenoid valve to the detergent container.
Unscrew the water fill pipe from the solenoid valve.
Push the two retainers indicated by the arrows towards the inside of the
appliance.
At the same time, turn the solenoid valve to remove it.
12.2.3 Control panel
Remove the worktop.

Electrolux WE170P Specifications

General

Door hinge	Left
Water fill	Cold, Hot
Drum volume	67 L
Control type	Buttons, Rotary
Display type	LCD
Loading type	Front-load
Drum material	Stainless steel
Product color	Gray
Built-in display	Yes
Appliance placement	Freestanding
Dispenser tray type	3-way
Drying capacity	- kg
Cycle time (max)	210 min
Washing capacity	8 kg
AquaStop function	No
Spin-drying class	-
Cycle time washing	70 min
Maximum spin speed	- RPM
Minimum spin speed	1400 RPM
Noise level (spin)	75 dB
Noise level (wash)	49 dB
Noise level (drying)	- dB
Number of washing programs	16
Cycle time (quick washing program)	20 min
Connected load	2000 W
AC input voltage	230 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Water consumption per cycle	47 L
Water consumption washing per cycle	65 L
Energy consumption washing per cycle	0.7 kWh
Water consumption washing & drying per cycle	- L
Energy consumption washing & drying per cycle	- kWh

Weight and Dimensions

Depth	624 mm
Width	597 mm
Height	850 mm
Weight	80.5 g
Package depth	701 mm
Package width	630 mm
Package height	900 mm
Package weight	82 g
Depth with door open	1066 mm
